Greenspace Flex

It delivers super flexibility, complete product range and seamlessly system integration to Hospitality customers..

Popular downloads

Products

Product				Compare
RS378B P11 940 PSD-E NB M55 911401536471 Greenspace Flex, 11 W, 940 neutral white, DALI, IP20 \| Finger-protected	78	858	4000	Product leaflet PDF
RS378B P15 927 PSU-E NB M55 911401721252 Greenspace Flex, 15 W, 927 warm white, IP20 \| Finger-protected	85	510	2700	Product leaflet PDF
RS378B P33 940 PSD-E NB M87 911401539171 Greenspace Flex, 33 W, 940 neutral white, DALI, IP20 \| Finger-protected	73	2400	4000	Product leaflet PDF
RS378B P42 940 PSD-E WB M102 911401540271 Greenspace Flex, 42 W, 940 neutral white, DALI, IP20 \| Finger-protected	97	4074	4000	Product leaflet PDF
RS378B P15 930 PSD-E WW S 911401546771 Greenspace Flex, 15 W, 930 warm white, DALI, IP20 \| Finger-protected	82	900	3000	Product leaflet PDF
RS378B P6 940 PSD-E NB M55 911401535571 Greenspace Flex, 6 W, 940 neutral white, DALI, IP20 \| Finger-protected	88	530	4000	Product leaflet PDF
RS378B P15 927 PSR-E 1-10V MB M55 911401540471 Greenspace Flex, 15 W, 927 warm white, Analog, IP20 \| Finger-protected	104	4386	2700	Product leaflet PDF
RS378B P6 930 PSU-E MB M43 911401532671 Greenspace Flex, 6 W, 930 warm white, IP20 \| Finger-protected	97	4074	3000	Product leaflet PDF

85 items

of 11

Products per page

Description

GreenSpace Flex is performance portfolio dedicated to Hospitality segment for GC/GM countries. With modular design concept, the light engines and different trims could have multiply of combination to satisfy diversified customer’s requirement.

Benefits

Complete portfolio covering from 400lm to 3000lm, 3CCT and 3 beam angles.
Super flexibility with modular design, and different trims to suit different application.
Smart connectivity to seamlessly integration with Interact Hospitality.
Deep recess for visual comfort
Easy installation and maintenance

Features

6w ~42w (400lm~3200lm)
CRI 90, SDCM <3
Beam Angle: NB, MB, WB
CCT: 2700K, 3000K, 4000K
High reliability, 50Khrs (L80B50@25°C)

Applications

Guest room, Bath room, Corridor, Lobby

See what’s trending: Explore popular products in these families

Tl-D Standard Colours

Coreline Waterproof

Optivision Led Gen3.5

Coreline Slimdownlight

Mounting type
Recessed
Operating Temperature range
-20 to +45 ºC
Light Source
COB
Mains Voltage
220-240V AC/ 50-60Hz
Optical Accessories
available through ETO
Dimming
PSU: non-dimmable PSD: dimmable via Dali protocol PSR: trailing dimmable PSR 1-10V: 1-10v dimmable DMX: dimmable via DMX protocol
Control system input
DALI / 1-10V / DMX / trailing edge
Material
Heat sink: die-cast aluminum
Main color of the luminaire
Housing: dark Grey Reflector: color available through ETO
Lumen maintenance at median useful life 50.000h
L80
Luminous flux
468-3990lm
Power consumption
6W-42W
Correlated color temperature - CCT
2700K, 3000K, 4000K
Color Rendering index - CRI
90
Beam angle
NB (Narrow Beam): 15-18° MB (Medium Beam): 20-24° WB (Wide Beam): 30-40° VWB (Very Wide Beam): 50°
Protection Class IEC61140
Class II & Class III for MR16 version
Mechanical impact protection
IK04
Ingress protection
IP20 / IP54(Front side) for selected SKU only
Light source replaceable
No
Driver replaceable
yes
Overall diameter
D55-D150
Installation
recessed Fixation by means of spring fasteners
