    • Elegant outlook design projector for the retail segment

      RS700B LED20 930PW PSU WB BK
      RS700B LED20 930PW PSU WB BK
      Truefashon Projector GCGM

      RS700B LED20 930PW PSU WB BK

      Order code: 911401520371

      Full Product Code: 911401520371

    Specifications Show all

    General Information
    Lamp colour code
    930 warm white
    Optical cover/lens type
    Lens
    Control interface
    -
    Protection class IEC
    Safety class II (II)
    CE mark
    CE mark
    Number of products on MCB (16 A type B)
    1
    Light source engine type
    LED
    Operating and Electrical
    Input Voltage
    220 to 240 V
    Input frequency
    50 or 60 Hz
    Power factor (min.)
    0.97
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Housing material
    Aluminium
    Optical cover/lens material
    Polymethyl methacrylate
    Optical cover/lens finish
    -
    Overall height
    70 mm
    Overall diameter
    96 mm
    Colour
    Black
    Approval and Application
    Ingress protection code
    IP20  [ Finger-protected]
    Mech. impact protection code
    -
    Initial Performance (IEC Compliant)
    Initial luminous flux (system flux)
    1586 lm
    Luminous flux tolerance
    +/-10%
    Initial LED luminaire efficacy
    75 lm/W
    Lamp colour temperature
    3000 K
    Colour Rendering Index
    >90
    Initial input power
    21 W
    Power consumption tolerance
    +/-10%
    Application Conditions
    Ambient temperature range
    -15 to +35 °C
    Product Data
    Full product code
    911401520371
    Order product name
    RS700B LED20 930PW PSU WB BK
    Order code
    911401520371
    SAP numerator – quantity per pack
    1
    Numerator – packs per outer box
    1
    SAP material
    911401520371
    SAP net weight (piece)
    0.330 kg
    Installation Diagrams
    Downloads
    Product Data Sheets
    Visuals
