CDM-T Elite 210W/930 PGZ18.1CT/12

Specifications Show all

Operating and Electrical

Power Consumption	210.0 W
Voltage (Nom)	100 V
Voltage (Nom)	100 V

Product Data

Full product name	CDM-T Elite 210W/930 PGZ18.1CT/12
Material number (12NC)	928601164731
Order code	928601164731
EAN/UPC - Case	8718291139515
Order product name	CDM-T Elite 210W/930 PGZ18.1CT/12
Numerator - Packs per outer box	12
Numerator - Quantity Per Pack	1
Full product code	871829113950800

Approval and Application

Energy Consumption kWh/1000 h	210 kWh
Mercury (Hg) Content (Max)	24 mg
EPREL Registration Number	473296
Energy Efficiency Class	F

Controls and Dimming

Dimmable

No

Mechanical and Housing

Bulb Shape	TMW28  [TMW 28mm]
Bulb Finish	Clear

General Information

Cap-Base	PGZ18  [PGZ18]
Flux measurement reference	Sphere
Operating Position	UNIVERSAL  [Any or Universal (U)]
Features	na  [Not Applicable]

Light Technical

Color rendering index (CRI)	90
Correlated Color Temperature (Nom)	3000 K
Chromaticity Coordinate X (Nom)	0.434
Chromaticity Coordinate Y (Nom)	0.398
Color Designation	Warm White (WW)
Luminous Efficacy (rated) (Nom)	114 lm/W
Luminous Efficacy (Rated) (Min)	105 lm/W
Color Code	930  [CCT of 3000K]
Luminous Flux	24,000 lumen
Saturated Red (R9)	50
